Implement Milvus CLI by Python Click

Overview

Project URL: https://github.com/milvus-io/milvus_cli

Preparation: Python3.8, Click 8.0.x

Group commands

Create a command

import click
from utils import PyOrm
@click.group(no_args_is_help=False, add_help_option=False, invoke_without_command=True)
@click.pass_context
def cli(ctx):
“""Milvus CLI""”
ctx.obj = PyOrm() # PyOrm is a util class which wraps the milvus python SDK. You can pass any class instance here. Any command function passed by @click.obj can call it.
if name == 'main':
cli()

As the code above, we use @click.group() to create a command group cli as entry point. To implement a prompt CLI we need to disable help messages for the entry, so we add no_args_is_help=False, add_help_option=False and invoke_without_command=True. And nothing will be printed if we input cli in terminal only.

Besides we use @click.pass_context to pass a context to this group for further usage.

Create a sub command of command group

Then we add the first sub command help under cli:

# Print the help message of specified command.
def print_help_msg(command):
    with click.Context(command) as ctx:
        click.echo(command.get_help(ctx))
# Use @cli.command() to create a sub command of cli.
@cli.command()
def help():
“""Show help messages.""”
# Print help message of cli.
click.echo(print_help_msg(cli))

Now we can use cli help in terminal:

$ python milvus_cli/scripts/milvus_cli.py help

Create a sub group of a command group

Not only we want to have a sub command like cli help, but also we need a sub group commands such as cli list collection , cli list partition and cli list indexes.

First we create a sub group command list, here we can pass the first parameter to @cli.group as the command name instead of use defult function name, so that we can reduce duplicated function names.

Attention here, we use @cli.group() instead of @click.group so that we create a sub group of origin group.

The we use @click.pass_obj to pass the context.obj to sub commands of this sub group.

@cli.group('list', no_args_is_help=False)
@click.pass_obj
def listDetails(obj):
    """List collections, partitions and indexes."""
    pass

Then we add some sub commands into this sub group by @listDetails.command() (not @cli.command()). Here’s just an example, you can ignore the implement and we will discuss it later.

@listDetails.command()
@click.option('--timeout', 'timeout', help="[Optional] - An optional duration of time in seconds to allow for the RPC. When timeout is set to None, client waits until server response or error occur.", default=None)
@click.option('--show-loaded', 'showLoaded', help="[Optional] - Only show loaded collections.", default=False)
@click.pass_obj
def collections(obj, timeout, showLoaded):
    """List all collections."""
    try:
        obj.checkConnection()
        click.echo(obj.listCollections(timeout, showLoaded))
    except Exception as e:
        click.echo(message=e, err=True)
@listDetails.command()
@click.option('-c’, ‘–collection’, ‘collection’, help=‘The name of collection.’, default=‘’)
@click.pass_obj
def partitions(obj, collection):
“""List all partitions of the specified collection.""”
try:
obj.checkConnection()
validateParamsByCustomFunc(
obj.getTargetCollection, ‘Collection Name Error!’, collection)
click.echo(obj.listPartitions(collection))
except Exception as e:
click.echo(message=e, err=True)

After all these complete, we have a miltigroup commands that look like:


Custom a command

Add options

You can add some options to a command which will be used like cli --test-option value.

Here’s an example, we add three options alias, host and port to specified an address to connect to Milvus.

First two parameters define the short and full option name, the third parameter defines the variable name, the help parameter specifies the short help message, the default parameter specifies the default value and the type specifies the value type.

And all options’ values will be passed into the function in order of definition.

@cli.command(no_args_is_help=False)
@click.option('-a', '--alias', 'alias', help="Milvus link alias name, default is `default`.", default='default', type=str)
@click.option('-h', '--host', 'host', help="Host name, default is `127.0.0.1`.", default='127.0.0.1', type=str)
@click.option('-p', '--port', 'port', help="Port, default is `19530`.", default=19530, type=int)
@click.pass_obj
def connect(obj, alias, host, port):
    pass

Add flag options

We use options above to pass a value, but some times we just need a flag as a boolean value.

As the example below, option autoId is a flag option and don’t pass any data to function, so we can use it like cli create collection -c c_name -p p_name -a.

@createDetails.command('collection')
@click.option('-c', '--collection-name', 'collectionName', help='Collection name to be created.', default='')
@click.option('-p', '--schema-primary-field', 'primaryField', help='Primary field name.', default='')
@click.option('-a', '--schema-auto-id', 'autoId', help='Enable auto id.', default=False, is_flag=True)
@click.pass_obj
def createCollection(obj, collectionName, primaryField, autoId, description, fields):
    pass

Add arguments

In this project we replace all arguments usage with options usage. But we still introduce argument usage here. Different from options, argements are used like cli COMMAND [OPTIONS] ARGUEMENTS. If we convert the example above into arguements usage, it’ll be like this:

@createDetails.command('collection')
@click.argument('collectionName')
@click.option('-p', '--schema-primary-field', 'primaryField', help='Primary field name.', default='')
@click.option('-a', '--schema-auto-id', 'autoId', help='Enable auto id.', default=False, is_flag=True)
@click.pass_obj
def createCollection(obj, collectionName, primaryField, autoId, description, fields):
    pass

Then the usage should be cli create collection c_name -p p_name -a.

Add full help message

As we define the short help message above, we can define the full help message in function:

@cli.command(no_args_is_help=False)
@click.option('-a', '--alias', 'alias', help="Milvus link alias name, default is `default`.", default='default', type=str)
@click.option('-h', '--host', 'host', help="Host name, default is `127.0.0.1`.", default='127.0.0.1', type=str)
@click.option('-p', '--port', 'port', help="Port, default is `19530`.", default=19530, type=int)
@click.pass_obj
def connect(obj, alias, host, port):
    """
    Connect to Milvus.
Example:

    milvus_cli &gt; connect -h 127.0.0.1 -p 19530 -a default
&quot;&quot;&quot;</span>
<span class="hljs-keyword">try</span>:
    obj.connect(alias, host, port)
<span class="hljs-keyword">except</span> Exception <span class="hljs-keyword">as</span> e:
    click.echo(message=e, err=<span class="hljs-literal">True</span>)
<span class="hljs-keyword">else</span>:
    click.echo(<span class="hljs-string">&quot;Connect Milvus successfully!&quot;</span>)
    click.echo(obj.showConnection(alias))

The first block inside of the function is the help message which will be printed after we input cli connect --help.

milvus_cli > connect --help
Usage: milvus_cli.py connect [OPTIONS]
Connect to Milvus.
Example:
  milvus_cli &gt; connect -h <span class="hljs-number">127.0</span><span class="hljs-number">.0</span><span class="hljs-number">.1</span> -p <span class="hljs-number">19530</span> -a <span class="hljs-literal">default</span>

Options:
-a, –alias TEXT    Milvus link alias name, default is <span class="hljs-literal">default</span>.
-h, --host TEXT     Host name, default is <span class="hljs-number">127.0</span><span class="hljs-number">.0</span><span class="hljs-number">.1</span>.
-p, --port INTEGER  Port, default is <span class="hljs-number">19530</span>.
–help              Show this message and exit.

Add confirm

Sometimes we need user to confirm some action especially delete something. We can add click.confirm to pause and ask user to confirm:

@deleteSth.command('collection')
@click.option('-c', '--collection', 'collectionName', help='The name of collection to be deleted.', default='')
@click.option('-t', '--timeout', 'timeout', help='An optional duration of time in seconds to allow for the RPC. If timeout is set to None, the client keeps waiting until the server responds or an error occurs.', default=None, type=int)
@click.pass_obj
def deleteCollection(obj, collectionName, timeout):
    """
    Drops the collection together with its index files.
Example:

    milvus_cli &gt; delete collection -c car
&quot;&quot;&quot;</span>
click.echo(
    <span class="hljs-string">&quot;Warning!\nYou are trying to delete the collection with data. This action cannot be undone!\n&quot;</span>)
<span class="hljs-keyword">if</span> <span class="hljs-keyword">not</span> click.confirm(<span class="hljs-string">&#x27;Do you want to continue?&#x27;</span>):
    <span class="hljs-keyword">return</span>
<span class="hljs-keyword">pass</span>

As the example above, a confirm conversation will show like Aborted!ant to continue? [y/N]:.

Add prompts

To implement prompts we juest need to add click.prompt.

@cli.command()
@click.pass_obj
def query(obj):
    """
    Query with a set of criteria, and results in a list of records that match the query exactly.
    """
    collectionName = click.prompt(
        'Collection name', type=click.Choice(obj._list_collection_names()))
    expr = click.prompt('The query expression(field_name in [x,y])')
    partitionNames = click.prompt(
        f'The names of partitions to search(split by "," if multiple) {obj._list_partition_names(collectionName)}', default='')
    outputFields = click.prompt(
        f'Fields to return(split by "," if multiple) {obj._list_field_names(collectionName)}', default='')
    timeout = click.prompt('timeout', default='')
    pass

The prompt will show when each click.prompt. We use a few prompts in series so that it’ll look like a continuously conversation. This ensure user will input the data in order we want. In this case we need user to choose a collection first, and we need to get all partitions under this collections, then show them to user to choose.

Add choices

Sometimes you want user just input the limited range/type of value, you can add type=click.Choice([<any>]) to click.prompt , click.options and etc…

Such as,

collectionName = click.prompt(
        'Collection name', type=click.Choice(['collection_1', 'collection_2']))

Then user can only input collection_1 or collection_2 , error will be raised if any other inputs.

Add clear screen

You can use click.clear() to implement it.

@cli.command()
def clear():
    """Clear screen."""
    click.clear()

Additional tips

Default value is None, so it’s meaningless if you specified the default value as None. And default None will cause click.prompt continously show if you want to leave a value empty to jump over it.

Implement prompt CLI for user to input

Why prompt CLI

For database operation, we need a continuously connection to a instance. If we use origin command line mode, the connection will be dropped after each command performed. We also want to store some data when using CLI, and clean them after exit.

Implement

Use while True for continuously listening user’s input.

def runCliPrompt():
    while True:
        astr = input('milvus_cli > ')
        try:
            cli(astr.split())
        except SystemExit:
            # trap argparse error message
            # print('error', SystemExit)
            continue
if name == 'main':
runCliPrompt()

Use input only will cause up, down, left, right arrow keys, tab key and some other keys converted to Acsii string automatically. Besides history commands can not be read from session. So we add readline into runCliPrompt function.

def runCliPrompt():
    while True:
            import readline
        readline.set_completer_delims(' \t\n;')
        astr = input('milvus_cli > ')
        try:
            cli(astr.split())
        except SystemExit:
            # trap argparse error message
            # print('error', SystemExit)
            continue

Add quit CLI.

@cli.command('exit')
def quitapp():
    """Exit the CLI."""
    global quitapp
    quitapp = True
quitapp = False  # global flag
def runCliPrompt():
while not quitapp:
import readline
readline.set_completer_delims(' \t\n;’)
astr = input('milvus_cli > ')
try:
cli(astr.split())
except SystemExit:
# trap argparse error message
# print('error’, SystemExit)
continue

Catch KeyboardInterrupt error when use ctrl C to exit.

def runCliPrompt():
    try:
        while not quitapp:
            import readline
            readline.set_completer_delims(' \t\n;')
            astr = input('milvus_cli > ')
            try:
                cli(astr.split())
            except SystemExit:
                # trap argparse error message
                # print('error', SystemExit)
                continue
    except KeyboardInterrupt:
        sys.exit(0)

After all settled, the CLI now looks like:

milvus_cli >
milvus_cli > connect
+-------+-----------+
| Host  | 127.0.0.1 |
| Port  |   19530   |
| Alias |  default  |
+-------+-----------+
milvus_cli > help
Usage:  [OPTIONS] COMMAND [ARGS]…
Milvus CLI
Commands:
clear     Clear screen.
connect   Connect to Milvus.
create    Create collection, partition and index.
delete    Delete specified collection, partition and index.
describe  Describe collection or partition.
exit      Exit the CLI.
help      Show help messages.
import    Import data from csv file with headers and insert into target…
list      List collections, partitions and indexes.
load      Load specified collection.
query     Query with a set of criteria, and results in a list of…
release   Release specified collection.
search    Conducts a vector similarity search with an optional boolean…
show      Show connection, loading_progress and index_progress.
version   Get Milvus CLI version.
milvus_cli > exit

Manually implement autocomplete

Different from click’s shell autocomplete, our project wrap the command line and use a loop to get user’s input to implement a prompt command line. So we need to bind a completer to readline.

class Completer(object):
    RE_SPACE = re.compile('.*\s+$', re.M)
    CMDS_DICT = {
        'clear': [],
        'connect': [],
        'create': ['collection', 'partition', 'index'],
        'delete': ['collection', 'partition', 'index'],
        'describe': ['collection', 'partition'],
        'exit': [],
        'help': [],
        'import': [],
        'list': ['collections', 'partitions', 'indexes'],
        'load': [],
        'query': [],
        'release': [],
        'search': [],
        'show': ['connection', 'index_progress', 'loading_progress'],
        'version': [],
    }
<span class="hljs-keyword">def</span> <span class="hljs-title function_">__init__</span>(<span class="hljs-params">self</span>) -&gt; <span class="hljs-literal">None</span>:
    <span class="hljs-built_in">super</span>().__init__()
    <span class="hljs-variable language_">self</span>.COMMANDS = <span class="hljs-built_in">list</span>(<span class="hljs-variable language_">self</span>.CMDS_DICT.keys())
    <span class="hljs-variable language_">self</span>.createCompleteFuncs(<span class="hljs-variable language_">self</span>.CMDS_DICT)

<span class="hljs-keyword">def</span> <span class="hljs-title function_">createCompleteFuncs</span>(<span class="hljs-params">self, cmdDict</span>):
    <span class="hljs-keyword">for</span> cmd <span class="hljs-keyword">in</span> cmdDict:
        sub_cmds = cmdDict[cmd]
        complete_example = <span class="hljs-variable language_">self</span>.makeComplete(cmd, sub_cmds)
        <span class="hljs-built_in">setattr</span>(<span class="hljs-variable language_">self</span>, <span class="hljs-string">&#x27;complete_%s&#x27;</span> % cmd, complete_example)

<span class="hljs-keyword">def</span> <span class="hljs-title function_">makeComplete</span>(<span class="hljs-params">self, cmd, sub_cmds</span>):
    <span class="hljs-keyword">def</span> <span class="hljs-title function_">f_complete</span>(<span class="hljs-params">args</span>):
        <span class="hljs-string">f&quot;Completions for the <span class="hljs-subst">{cmd}</span> command.&quot;</span>
        <span class="hljs-keyword">if</span> <span class="hljs-keyword">not</span> args:
            <span class="hljs-keyword">return</span> <span class="hljs-variable language_">self</span>._complete_path(<span class="hljs-string">&#x27;.&#x27;</span>)
        <span class="hljs-keyword">if</span> <span class="hljs-built_in">len</span>(args) &lt;= <span class="hljs-number">1</span> <span class="hljs-keyword">and</span> <span class="hljs-keyword">not</span> cmd == <span class="hljs-string">&#x27;import&#x27;</span>:
            <span class="hljs-keyword">return</span> <span class="hljs-variable language_">self</span>._complete_2nd_level(sub_cmds, args[-<span class="hljs-number">1</span>])
        <span class="hljs-keyword">return</span> <span class="hljs-variable language_">self</span>._complete_path(args[-<span class="hljs-number">1</span>])
    <span class="hljs-keyword">return</span> f_complete

<span class="hljs-keyword">def</span> <span class="hljs-title function_">_listdir</span>(<span class="hljs-params">self, root</span>):
    <span class="hljs-string">&quot;List directory &#x27;root&#x27; appending the path separator to subdirs.&quot;</span>
    res = []
    <span class="hljs-keyword">for</span> name <span class="hljs-keyword">in</span> os.listdir(root):
        path = os.path.join(root, name)
        <span class="hljs-keyword">if</span> os.path.isdir(path):
            name += os.sep
        res.append(name)
    <span class="hljs-keyword">return</span> res

<span class="hljs-keyword">def</span> <span class="hljs-title function_">_complete_path</span>(<span class="hljs-params">self, path=<span class="hljs-literal">None</span></span>):
    <span class="hljs-string">&quot;Perform completion of filesystem path.&quot;</span>
    <span class="hljs-keyword">if</span> <span class="hljs-keyword">not</span> path:
        <span class="hljs-keyword">return</span> <span class="hljs-variable language_">self</span>._listdir(<span class="hljs-string">&#x27;.&#x27;</span>)
    dirname, rest = os.path.split(path)
    tmp = dirname <span class="hljs-keyword">if</span> dirname <span class="hljs-keyword">else</span> <span class="hljs-string">&#x27;.&#x27;</span>
    res = [os.path.join(dirname, p)
           <span class="hljs-keyword">for</span> p <span class="hljs-keyword">in</span> <span class="hljs-variable language_">self</span>._listdir(tmp) <span class="hljs-keyword">if</span> p.startswith(rest)]
    <span class="hljs-comment"># more than one match, or single match which does not exist (typo)</span>
    <span class="hljs-keyword">if</span> <span class="hljs-built_in">len</span>(res) &gt; <span class="hljs-number">1</span> <span class="hljs-keyword">or</span> <span class="hljs-keyword">not</span> os.path.exists(path):
        <span class="hljs-keyword">return</span> res
    <span class="hljs-comment"># resolved to a single directory, so return list of files below it</span>
    <span class="hljs-keyword">if</span> os.path.isdir(path):
        <span class="hljs-keyword">return</span> [os.path.join(path, p) <span class="hljs-keyword">for</span> p <span class="hljs-keyword">in</span> <span class="hljs-variable language_">self</span>._listdir(path)]
    <span class="hljs-comment"># exact file match terminates this completion</span>
    <span class="hljs-keyword">return</span> [path + <span class="hljs-string">&#x27; &#x27;</span>]

<span class="hljs-keyword">def</span> <span class="hljs-title function_">_complete_2nd_level</span>(<span class="hljs-params">self, SUB_COMMANDS=[], cmd=<span class="hljs-literal">None</span></span>):
    <span class="hljs-keyword">if</span> <span class="hljs-keyword">not</span> cmd:
        <span class="hljs-keyword">return</span> [c + <span class="hljs-string">&#x27; &#x27;</span> <span class="hljs-keyword">for</span> c <span class="hljs-keyword">in</span> SUB_COMMANDS]
    res = [c <span class="hljs-keyword">for</span> c <span class="hljs-keyword">in</span> SUB_COMMANDS <span class="hljs-keyword">if</span> c.startswith(cmd)]
    <span class="hljs-keyword">if</span> <span class="hljs-built_in">len</span>(res) &gt; <span class="hljs-number">1</span> <span class="hljs-keyword">or</span> <span class="hljs-keyword">not</span> (cmd <span class="hljs-keyword">in</span> SUB_COMMANDS):
        <span class="hljs-keyword">return</span> res
    <span class="hljs-keyword">return</span> [cmd + <span class="hljs-string">&#x27; &#x27;</span>]

<span class="hljs-keyword">def</span> <span class="hljs-title function_">complete</span>(<span class="hljs-params">self, text, state</span>):
    <span class="hljs-string">&quot;Generic readline completion entry point.&quot;</span>
    buffer = readline.get_line_buffer()
    line = readline.get_line_buffer().split()
    <span class="hljs-comment"># show all commands</span>
    <span class="hljs-keyword">if</span> <span class="hljs-keyword">not</span> line:
        <span class="hljs-keyword">return</span> [c + <span class="hljs-string">&#x27; &#x27;</span> <span class="hljs-keyword">for</span> c <span class="hljs-keyword">in</span> <span class="hljs-variable language_">self</span>.COMMANDS][state]
    <span class="hljs-comment"># account for last argument ending in a space</span>
    <span class="hljs-keyword">if</span> <span class="hljs-variable language_">self</span>.RE_SPACE.<span class="hljs-keyword">match</span>(buffer):
        line.append(<span class="hljs-string">&#x27;&#x27;</span>)
    <span class="hljs-comment"># resolve command to the implementation function</span>
    cmd = line[<span class="hljs-number">0</span>].strip()
    <span class="hljs-keyword">if</span> cmd <span class="hljs-keyword">in</span> <span class="hljs-variable language_">self</span>.COMMANDS:
        impl = <span class="hljs-built_in">getattr</span>(<span class="hljs-variable language_">self</span>, <span class="hljs-string">&#x27;complete_%s&#x27;</span> % cmd)
        args = line[<span class="hljs-number">1</span>:]
        <span class="hljs-keyword">if</span> args:
            <span class="hljs-keyword">return</span> (impl(args) + [<span class="hljs-literal">None</span>])[state]
        <span class="hljs-keyword">return</span> [cmd + <span class="hljs-string">&#x27; &#x27;</span>][state]
    results = [
        c + <span class="hljs-string">&#x27; &#x27;</span> <span class="hljs-keyword">for</span> c <span class="hljs-keyword">in</span> <span class="hljs-variable language_">self</span>.COMMANDS <span class="hljs-keyword">if</span> c.startswith(cmd)] + [<span class="hljs-literal">None</span>]
    <span class="hljs-keyword">return</span> results[state]

After define Completer we can bind it with readline:

comp = Completer()
def runCliPrompt():
try:
while not quitapp:
import readline
readline.set_completer_delims(' \t\n;’)
readline.parse_and_bind(“tab: complete”)
readline.set_completer(comp.complete)
astr = input('milvus_cli > ')
try:
cli(astr.split())
except SystemExit:
# trap argparse error message
# print('error’, SystemExit)
continue
except KeyboardInterrupt:
sys.exit(0)

Add one-time option

For prompt command line, sometimes we don’t want to fully run into the scripts to get some informations such as version. A good example is Python, when you type python in terminal the promtp command line will show, but it only returns a version message and will not entry the prompt scripts if you type python -V. So we can use sys.args in our code to implement.

def runCliPrompt():
    args = sys.argv
    if args and (args[-1] == '--version'):
        print(f"Milvus Cli v{getPackageVersion()}")
        return
    try:
        while not quitapp:
            import readline
            readline.set_completer_delims(' \t\n;')
            readline.parse_and_bind("tab: complete")
            readline.set_completer(comp.complete)
            astr = input('milvus_cli > ')
            try:
                cli(astr.split())
            except SystemExit:
                # trap argparse error message
                # print('error', SystemExit)
                continue
    except KeyboardInterrupt:
        sys.exit(0)
if name == 'main':
runCliPrompt()

We get sys.args before the loop when first run into CLI scripts. If the last arguments is --version , the code will return the package version without running into loop.

It will be helpful after we build the codes as a package. User can type milvus_cli to jump into a prompt CLI, or type milvus_cli --version to only get the version.

Build and release

Finally we want to build a package and release by PYPI. So that user can simply use pip install <package name> to install.

Install locally for test

Before you publish the package to PYPI, you may want to install it locally for some tests.

In this case, you can simply cd into the package directory and run pip install -e . (Don’t forget the .).

Create package files

Refer to: https://packaging.python.org/tutorials/packaging-projects/

A package’s structure should look like:

package_example/
├── LICENSE
├── README.md
├── setup.py
├── src/
│   ├── __init__.py
│   ├── main.py
│   └── scripts/
│       ├── __init__.py
│       └── example.py
└── tests/

Create the package directory

Create Milvus_cli directory with the structure below:

Milvus_cli/
├── LICENSE
├── README.md
├── setup.py
├── milvus_cli/
│   ├── __init__.py
│   ├── main.py
│   ├── utils.py
│   └── scripts/
│       ├── __init__.py
│       └── milvus_cli.py
└── dist/

Write the entry code

The script’s entry should be in Milvus_cli/milvus_cli/scripts, and the Milvus_cli/milvus_cli/scripts/milvus_cli.py should be like:

import sys
import os
import click
from utils import PyOrm, Completer
pass_context = click.make_pass_decorator(PyOrm, ensure=True)
@click.group(no_args_is_help=False, add_help_option=False, invoke_without_command=True)
@click.pass_context
def cli(ctx):
“""Milvus CLI""”
ctx.obj = PyOrm()
“"”
…
Here your code.
…
“"”
@cli.command(‘exit’)
def quitapp():
“""Exit the CLI.""”
global quitapp
quitapp = True
quitapp = False  # global flag
comp = Completer()
def runCliPrompt():
args = sys.argv
if args and (args[-1] == ‘–version’):
print(f"Milvus Cli v{getPackageVersion()}")
return
try:
while not quitapp:
import readline
readline.set_completer_delims(' \t\n;’)
readline.parse_and_bind(“tab: complete”)
readline.set_completer(comp.complete)
astr = input('milvus_cli > ')
try:
cli(astr.split())
except SystemExit:
# trap argparse error message
# print('error’, SystemExit)
continue
except Exception as e:
click.echo(
message=f"Error occurred!\n{str(e)}", err=True)
except KeyboardInterrupt:
sys.exit(0)
if name == 'main':
runCliPrompt()

Edit the `setup.py`

from setuptools import setup, find_packages
with open(“README.md”, “r”, encoding=“utf-8”) as fh:
long_description = fh.read()
setup(
name=‘milvus_cli’,
version=‘0.1.6’,
author=‘Milvus Team’,
author_email=‘milvus-team@zilliz.com’,
url=‘https://github.com/milvus-io/milvus_cli’,
description=‘CLI for Milvus’,
long_description=long_description,
long_description_content_type=‘text/markdown’,
license=‘Apache-2.0’,
packages=find_packages(),
include_package_data=True,
install_requires=[
‘Click==8.0.1’,
‘pymilvus==2.0.0rc5’,
‘tabulate==0.8.9’
],
entry_points={
‘console_scripts’: [
‘milvus_cli = milvus_cli.scripts.milvus_cli:runCliPrompt’,
],
},
python_requires=‘>=3.8’
)

Some tips here:

We use README.md content as the package’s long description.
Add all dependencies to install_requires.
Specify the entry_points. In this case, we set milvus_cli as a child of console_scripts, so that we can type milvus_cli as a command directly after we install this package. And the milvus_cli's entry point is runCliPrompt function in milvus_cli/scripts/milvus_cli.py.

Build

Upgrade the build package: python3 -m pip install --upgrade build
Run build: python -m build --sdist --wheel --outdir dist/ .
Two files will be generated under the dist/ directory:

dist/
  example_package_YOUR_USERNAME_HERE-0.0.1-py3-none-any.whl
  example_package_YOUR_USERNAME_HERE-0.0.1.tar.gz

Publish release

Refer to: https://packaging.python.org/tutorials/packaging-projects/#uploading-the-distribution-archives

Upgrade twine package: python3 -m pip install --upgrade twine
Upload to PYPI test env: python3 -m twine upload --repository testpypi dist/*
Upload to PYPI : python3 -m twine upload dist/*

CI/CD by Github workflows

Refer to: https://packaging.python.org/guides/publishing-package-distribution-releases-using-github-actions-ci-cd-workflows/

We want a way to upload assets automatically, it can build the packages and upload them to github releases and PYPI.

(For some reason we just want the workflow only publish the release to test PYPI.)

# This is a basic workflow to help you get started with Actions
name: Update the release's assets after it published
on:
release:
# The workflow will run after release published
types: [published]
jobs:
build:
# The type of runner that the job will run on
runs-on: ubuntu-latest
# Steps represent a sequence of tasks that will be executed as part of the job
steps:
  # Checks-out your repository under $GITHUB_WORKSPACE, so your job can access it
  - uses: actions/checkout@v2
  - uses: actions/setup-python@v2
    with:
      python-version: &#x27;</span>3.8<span class="hljs-string">&#x27;
      architecture: &#x27;</span>x64<span class="hljs-string">&#x27;
  - name: Install pypa/build
    run: &gt;-
      python -m
      pip install
      build
      --user
  - name: Clean dist/
    run: |
      sudo rm -fr dist/*
  - name: Build a binary wheel and a source tarball
    run: &gt;-
      python -m
      build
      --sdist
      --wheel
      --outdir dist/
      .
  # Update target github release&#x27;</span>s assets
  - name: Update assets
    uses: softprops/action-gh-release@v1
    <span class="hljs-keyword">if</span>: startsWith(github.ref, <span class="hljs-string">&#x27;refs/tags/&#x27;</span>)
    with:
      files: ./dist/*
  - name: Publish distribution 📦 to Test PyPI
    <span class="hljs-keyword">if</span>: contains(github.ref, <span class="hljs-string">&#x27;beta&#x27;</span>) &amp;&amp; startsWith(github.ref, <span class="hljs-string">&#x27;refs/tags&#x27;</span>)
    uses: pypa/gh-action-pypi-publish@release/v1
    with:
      user: __token__
      password: <span class="hljs-variable">${{ secrets.TEST_PYPI_API_TOKEN }</span>}
      repository_url: https://test.pypi.org/legacy/
      packages_dir: dist/
      verify_metadata: <span class="hljs-literal">false</span>

Learn more about Milvus

Milvus is a powerful tool capable of powering a vast array of artificial intelligence and vector similarity search applications. To learn more about the project, check out the following resources:

Read our blog.
Interact with our open-source community on Slack.
Use or contribute to the world’s most popular vector database on GitHub.
Quickly test and deploy AI applications with our new bootcamp.

Try Managed Milvus for Free

Zilliz Cloud is hassle-free, powered by Milvus and 10x faster.

Get Started

Like the article? Spread the word

Overview

Overview

Group commands

Create a command

Create a sub command of command group

Create a sub group of a command group

Custom a command

Add options

Add flag options

Add arguments

Add full help message

Add confirm

Add prompts

Add choices

Add clear screen

Additional tips

Implement prompt CLI for user to input

Why prompt CLI

Implement

Manually implement autocomplete

Add one-time option

Build and release

Install locally for test

Create package files

Create the package directory

Write the entry code

Edit the `setup.py`

Build

Publish release

CI/CD by Github workflows

Learn more about Milvus

Try Managed Milvus for Free

Continua a Leggere

Dal recupero ai risultati strutturati: aggregazione e ORDER BY in Milvus 3.0

Oltre =~: come Milvus 3.0 trasforma le regex in un filtro nativo del database

Snapshot Milvus: viste delle raccolte point-in-time senza copiare i dati

Come recuperare i dati di Milvus dopo una corruzione di etcd senza un backup

Overview

Overview

Group commands

Create a command

Create a sub command of command group

Create a sub group of a command group

Custom a command

Add options

Add flag options

Add arguments

Add full help message

Add confirm

Add prompts

Add choices

Add clear screen

Additional tips

Implement prompt CLI for user to input

Why prompt CLI

Implement

Manually implement autocomplete

Add one-time option

Build and release

Install locally for test

Create package files

Create the package directory

Write the entry code

Edit the setup.py

Build

Publish release

CI/CD by Github workflows

Learn more about Milvus

Try Managed Milvus for Free

Continua a Leggere

Dal recupero ai risultati strutturati: aggregazione e ORDER BY in Milvus 3.0

Oltre =~: come Milvus 3.0 trasforma le regex in un filtro nativo del database

Snapshot Milvus: viste delle raccolte point-in-time senza copiare i dati

Come recuperare i dati di Milvus dopo una corruzione di etcd senza un backup

Edit the `setup.py`
